Complete Crushing and Screening Plant (Capacity Up to 600MTPH) - COM-CRU-330116

Complete Crushing and Screening Plant with Capacity Up To 600 MTPH.

This is a complete crushing and screening line that comes with all necessary components such as conveyor belts, feed hoppers, and control panel. All components of this plant are in excellent working condition and the plant is ready to work. This plant has been dismantled and is ready for transport.

Main Machinery used in Plant:

1. Telsmith 2 Step Grizzly Feeder 54x20”

Opening Size:1372mm x 6100mm

Power: 45kw

Capacity: Up to 930 TPH

2. Telsmith Jaw Crusher 4450

Motor Power: 160kw

Maximum Feed Size: Up to 1000mm

CSS: 125mm-305mm

Capacity: Up to 930 MTPH

Dimensions (L)x(W)x(H): 3353mm x 2896mm x 4083mm

3. 2x Metso HP 300 Cone Crusher

Motor Power: 220kw

Feed Opening: 241mm

Capacity: 440 MTPH

4. VSI Telsmith 4500

Motor Power: 373kw

Maximum Feed Size: 127mm

Feed Opening Diameter: 406mm

Capacity: Up to 450 MTPH

5. Telsmith 2-Deck Screen

1520mm x 4880mm

Motor Power: 22kw

6. Telsmith 3-Deck Screen

Screen Size: 7000mm x 2500mm

Motor Power: 45kw

7. Conveyors

Different sizes of conveyors with a total combined length of 475 Meters.
